Product Description:

  • Type Tested Assembly to IEC 61439-2 and IEC 60439-1.
  • Robust, modular and compact construction
  • Tested to comply with internal arc tests IEC/TR 61641
  • Front access switchboard suitable for mounting against a wall.
  • Rated operational voltage: 690V AC
  • Rated current: Up to 6300A
  • Rated short time withstand current: Up to 100kA
  • Ingress Protection class to IEC 529: IP 54
  • Height: 2000, 2200mm
  • Depth: 600, 800
  • Width: 400, 600, 800, 1000, 1200 mm
  • Typical form of separation: Form 1 to Form 4b
  • Colour RAL 7035 Epoxy-polyester paint

Ministry of Finance – MCC Panels

Completion of fifth batch for the LV Switchgear (MCC Panels) related to TECO Project No. 17082/TC named Ministry of Finance Complex (MOF).

Fine VFD Panel

fabrication works for 3x75KW and 1x22KW VFD Panel for M/S F.A. Kettaneh and end client is Fine Hygenic Holding Company.
